Item : 019375

Name : Molybdenum Rod

Price : Contact us

Details:

Availability

Molybdenum rod is manufactured as random length pieces or cut to customer�s desired lengths in diameters ranging from .020 inches to 1.75 inches. Standard diameter and length tolerances are listed in the accompanying tables. Other, closer tolerances can be quote on request. In addition, there are three different surface processes or finishes which are provided, depending on the desired end use.

Surface Finish

Black � Surface is �as swaged or �as drawn�; retaining a coating of processing lubricants and oxides.

Cleaned - Surface is chemically cleaned to remove all lubricants and oxides.

Ground - Surface is centerless ground to remove all coating and to achieve precise diameter control.

Standard Diameter Tolerances (inches)

Diameter Black/Clean Ground

.020 to .025 � .001 � .001

.025 to .070 � .0015 � .001

.070 to .200 � .002 � .001

.200 to .250 � .007 � .001

.250 to .435 � .007 � .0015

.425 to .750 � .010 � .003

.750 to 1.000 � .015 � .005

1.000 to 1.250 � .015 � .005

1.250 to 1.750 � .025 � .005

Tighter tolerances can be obtained upon request.

Standard Length Tolerances (Inches)

Diameter .5" to 12" 12" to 24" > 24"

.020 to .100 � .010 � .015 � .0625

.100 - .500 � .015 � .015 � .0625

.500 to 1.000 � .015 � .030 � .0625

1.000 to 1.500 � .030 � .0625 � .0625

Tighter tolerances can be obtained upon request.
